CS35 Lab 01: Image Editor

Due 11:59pm Sunday, February 4 2018

This is an individual assignment. You must complete this lab on your own, although you may discuss lab concepts with other students. Please keep the Academic Integrity Policy in mind---do not show your code to anyone outside of the professors and ninjas, and do not look at anyone else's code for this lab. If you need help, please post a question on Piazza, or contact the professors or ninjas.

The goal of this lab is to introduce you to basic concepts in the C++ program language. Concepts you will be familiar with after this lab include:

In addition, you will become somewhat familiar with image processing and the concept of buffering.

Please get a copy of the starter code for this lab by cloning the appropriate git repository, e.g.:

$ cd ~/cs35/labs
$ git clone git@github.swarthmore.edu:CS35-S18/lab01-<user>.git ./lab01
For this lab, we also are hosting several test image files. Instead of giving everyone identical copies of the somewhat large files, you will create a symbolic link to the folder containing the files.
$ cd ~/cs35/labs/lab01
$ ln -s /usr/local/doc/lab01-images/  ./test_data
Useful links (visit after reading the lab):
Introduction

This lab will have you write a program to load and output image files. In addition, you will provide a user the option to perform some basic image manipulation, including color alteration and horizontal flipping. To begin, we will first learn about the PPM Image format. Click here for information about the PPM format (and how to parse it) as well as tips for viewing and creating PPM image files.

Reading about the PPM format may seem overwhelming, but it's actually fairly simple to get started. You will write a program called picfilter which allows the user to manipulate PPM files. Your program will read a PPM file into memory as an array, perform a transformation on it, and then save it in another PPM file. Your program will ask the user to enter the name of the input PPM file, the name of the output PPM file, and the name of the transformation to perform.

$  clang++ -std=c++11 -o picfilter picfilter.cpp image.cpp ppmio.cpp
$  ./picfilter
Welcome to the Portable Pixmap (PPM) Image Editor

Enter name of input file:  test_data/MachuPicchu.ppm
Enter name of output file:  output.ppm
Enter filter command:  grayscale

Image converted.  Goodbye!
The original and resulting image:

MachuPicchu.ppm MachuPicchu-gray.ppm

Reading PPMs

To read a PPM file, you will pass its filename to three functions:

The array of pixels may be larger than you'd expect; it will actually be three times the size of the number of pixels in the image. For instance, a 100x100 PPM image would produce an array of size 30,000. This is because each pixel is represented by three numbers: the amount of red, green, and blue light to show for the pixel. Each number ranges from 0 (no light) to 255 (all the light). Here are some example pixel values:

The read_ppm function takes care of opening a PPM file, reading the image data into it, and giving it back to you the array you provided. Once you've read the PPM, you can change it and then write it back out into another file using the corresponding write_ppm function. These functions are defined in ppmio.h.

Transforming PPMs

Once you've read in your PPM as an array of integers, it's up to you to change those integers in any way you like. You could loop over the entire image and set every number to 255, resulting in a giant white rectangle (since every pixel is now white). You could loop over each position in the first row and set each third number to 0, draining all of the blue light from the top line of the image.

As mentioned above, the user specifies an input file, a transformation, and an output file. Here are the transformations the user is allowed to request:

For each of these transformations, you will write a void function of the same name that takes an int array containing a PPM image and makes the appropriate changes. You will then complete a main function which asks a user for the name of the input and output files, as well as the transformation to perform, loads the image, calls the right transformation function, and then saves the result. If the user gives an invalid transformation (e.g. flipDiagonal), your program should tell the user so and ask again for a valid transformation. Keep asking until the user enters a valid transformation. You are allowed to ignore errors caused when the user gives non-existent or invalid filenames.

Writing Your Program

Your starter code has been separated into several files:

Compiling Your Program

To compile your program, clang++ will need to know about all three .cpp files. Make sure to include them in your compilation command:

$ clang++ -std=c++11 -o picfilter picfilter.cpp image.cpp ppmio.cpp

Getting Started

Remember: you don't have to write everything all at once. It's often best to get a small amount of your code to work and then move on to the next part. You can follow these steps to complete your lab:

  1. Start by completing your main function. Much of this code has been given to you -- we've already shown you how to define an array for the ppm file, ask the user for input/output file names, and read the file into an array. The starter file also recognizes when a user asks for noRed and calls the appropriate transformation function. First, you should add in code that tells the user when they've entered an invalid transformation, and you should write the transformed ppm image out to the output file. For now, assume that noRed is the only valid transformation.

  2. We've given you a function stub for noRed. This is an empty function definition that does nothing. At this point, you should be able to run picfilter, call noRed, and write the result out to a file; however, the output should match the input file. Next, implement noRed and verify that it removes all red from the input image.

  3. One by one, implement more transformations, adding them to main as you complete them. Try each of them out before you move on to the next one.

  4. flipHorizontally and flipVertically are significantly harder than the other transformations. We recommend that you work out the math on paper before attempting to write the code.

  5. Once you've finished writing your transformations, run your program several times and compare it to the files in test_data to see if your transformations work correctly.

Survey
When you have completed your lab, answer a few short survey questions in the file README.md
Creating Your Own PPM Files

You can use ImageMagick, a package installed on the CS network, together with picfilter to edit your own images! Start by converting your picture to PPM format:

$ convert my_image.jpg -compress none my_image.ppm

Then, do anything you want with picfilter:

$ ./picfilter
Welcome to the Portable Pixmap (PPM) Image Editor

Enter name of input file:  my_image.ppm
Enter name of output file:  my_image-gray.ppm
Enter filter command: grayscale

Image converted.  Goodbye!

Finally, convert your new image back to some other format.

$ convert my_image-gray.ppm my_image_2.jpg

There! You've just used your homework assignment to perform photo editing on your own files. :)

Summary

To summarize the requirements of this lab:

Submit

Once you are satisfied with your code, hand it in using git. Remember the add, commit, push development cycle. You can push as many times as you like, but only the most recent submission will be graded. You may want to run git status to confirm all modifications have been pushed.

Hints

It will be helpful to think about how the row and column indices in an image correspond to offsets into the array ppm. Consider the image below showing an image with width equal to three columns and height equal to two rows. The red, green, and blue values of each pixel are stored consecutively in the ppm array. All the pixels in the first row appear before all the pixels in the second row. It may be helpful to think of a function int getOffset(row, col, width, height) which computes the index into the ppm of the red value of the pixel at the given row and column for an image with a given width and height. Study the picture below and see if you can design this function. How does the index of the first element in the second row relate to the height and width of the image? How does the index of the third column relate to the index of the first column?

Acknowledgments

This lab write up is based off of Joshua Guerin and Debby Keen's NIFTY 2012 submission titled PPM Image Editor.
