This is a two-part lab:

1. An application that solves a maze using either breadth-first or depth-first search.
2. Written answers to questions regarding algorithmic analysis, induction, and invariants.

The main goals of this lab are to use data structures to implement algorithms and to gain practice using induction. Concepts you will be familiar with after this lab include:

• Stacks and Queues
• Depth-First Search
• Breadth-First Search
• gdb
• Induction
• Invariants

Note: This is a two-part, two-week lab assignment. However, the lab is due in three weeks because of fall break. This lab is not designed to make you work over fall break, nor are you expected to. There is however two weeks worth of work in this lab, and we do expect you to work on it this week. Plan accordingly.

As with most assignments for the rest of the semester, you will be working with a partner. Both partners should be present and working on the code together. You will both be responsible for understanding all concepts, so dividing and conquering is not an option. The academic integrity policy applies to the entire pair; you cannot work or share code with anyone outside your partner.

You and your lab partner will share the same git repository, which is named lab05-<user1>-<user2>.git. Please access your lab by cloning the appropriate git repository, e.g.:

$ git clone git@github.swarthmore.edu:CS35-F17/lab05-mgagne1-adanner1.git

You can also get the ssh git url from CS35 github org. For this lab, we also are hosting several test files. Instead of giving everyone identical copies of the somewhat large files, you will create a symbolic link to the folder containing the files.

$ cd ~/cs35/lab05
$ ln -s /usr/local/doc/lab05-data/  ./test_data

Images taken from UncleShuck's farm, Dawsonville, GA, and from The MAiZE Company.

In this lab, you will implement two search algorithms—depth-first search and breadth-first search—for finding a path through a maze.

Search Algorithms

In class last week, you saw the following search algorithm:

Algorithm MazeSearch:
  mark Start as visited
  add Start to DataStructure
  while (DataStructure is not empty):
    Current = remove location from DataStructure
    if (Current == Destination): // found a path!
      return Path found
    else for each Neighbor of Current:
      if Neighbor not visited:
        mark Neighbor visited
        add Neighbor to DataStructure
  return no Path exists

The way this algorithm traverses through locations depends on which data structure is used to store visited locations. When we use a stack, the algorithm is called Depth-First Search (DFS). When a queue is used, it is commonly called Breadth-First Search (BFS).

In this lab you will implement both DFS and BFS, use them to find paths through a 2-D maze, and explore how the two search algorithms produce different paths.

Below is an overview of the files required for submitting this lab. Those highlighted in blue will require implementation on your part. Those highlighted in black are complete and should not be modified except for comments.

• The ADTs you will use for this lab have been added to /usr/local/include/cs35/, the same directory as last week. You can have a look at the ADTs for stacks and queues here.
• C++ implementations of the List,Queue, and Stack ADTs using the C++ Standard Template Library (STL) are include in the files stlList.h, stlQueue.h, stlStack.h in the directory above. You will not have to implement a Stack or Queue this lab.
• position.h, position.cpp: The Position class, which keeps track of the contents of a position in a maze.
• maze.h, maze.cpp: The Maze class, which is used to represent a maze and provide solutions to it.
• mazeUtils.h, mazeUtils.cpp: definitions for Maze helper functions which load a maze from a file and render an answer.
• main.cpp: the main program which loads a maze from a file, solves it, and prints out the result.
• Makefile: The build instructions for your lab.
• test_data: a directory containing several maze files. The format is described below.
• tests.cpp: a collection of unit tests for your maze program.

ADT Implementations

For this and future labs, you will occasionally be provided with implementations of the ADTs we discussed in class. These implementations make use of the C++ Standard Template Library (STL) and are written as classes named e.g. STLList. To use these classes, simply #include the header the same way you normally would, e.g.,

/* ADTs */
#include <cs35/List.h>
#include <cs35/Stack.h>

/* Implementations */
#include <cs35/stlList.h>
#include <cs35/stlStack.h>

int main(){

  List<int>* list = new STLList<int>;
  STLStack<int> stack;
}

The Maze Layout

Each maze is a rectangular grid. Each space in the grid is assumed to be connected to the adjacent spaces (left, right, up, and down, but not the diagonally adjacent spaces. The starting point of each maze is the upper left corner; the exit is in the bottom right corner.

The layout of a particular maze will be stored in a file with the extension .map; you can find several examples in your test_data directory. A map file contains the following information:

• The width of the maze in squares (i.e., the number of columns in the map)
• The height of the column in squares (i.e., the number of rows in the map)
• For each row of the map, a string describing all of the spaces in that row.
  • Each # character is a wall.
  • Each . character is an open space.

For instance, the following is a valid map:

5 3
.#.#.
.#...
...#.

We have given you the code which loads files in this format; this explanation is just for reference.

The Position Class

We will represent a maze as a two-dimensional grid of pointers to Position objects. Each Position object contains relevant information for one place in the maze: the (X,Y) coordinates (where (0,0) is the upper-left), whether that position is a wall, and some fields which will be used during the search to construct an appropriate path through the maze. The constructor of the Position class should take the X and Y coordinate values and initialize the other fields to suitable default values (like nullptr or false).

The 2-D grid that you create for your maze should take the form of a data member positions of type Position***. This is an array of arrays of Position pointers. This way, you can write e.g. positions[0][0] to get the Position* which points to the Position object in the upper-left corner. You'll have to use nested for-loops to initialize positions correctly.

The Maze Class

A maze object represents our knowledge of a particular maze. We can use this information to find a path through the maze using various search algorithms. You will write two methods—solveDepthFirstSearch and solveBreadthFirstSearch—which are very similar. These methods will return a List*: a pointer to a list of Position pointers, which constitute a correct path through the maze from the start to the finish. If no such path exists, the method should return nullptr.

You have been given the declaration of the maze class. You only need to implement each of the methods. The real magic of making the program work happens in these methods, which find a path through the maze using the search algorithm given above.

At the end of the loop, you can determine whether a path has been found by looking at the exit position and seeing if it has been visited. If so, you just need to follow the previous position pointers backward until you reach the start. This gives you the path to take (in reverse order). If the exit position has not been visited, then there is no possible path through the maze.

Testing the Maze class

Make sure to run the unit tests we've provided on your code as you develop. Definitely test your code once you've finished the Maze class! It will be easier to find bugs in your Maze implementation by direct testing than it will be by trying to find them by hand running the maze program.

Some of the map files in test_data have multiple possible solutions. As a result, your output may differ from the provided solutions depending on how you explore the maze. To get the same results as the provided solutions, you should explore neighboring spaces in the following order: up, left, right, and then down.

Implementing Main

The implementation of main should be less work than the Maze class. It just involves something assembling the pieces you've constructed above. The loadMap and renderAnswer functions have been written for you. loadMap will read a map file and return a Maze* if loading was successful. Otherwise, it will throw a runtime_error. renderAnswer should produce a string containing a solution, which looks like the map from the input file, but contains @ characters on the path you found. For example, here is a possible execution of the program:

$ ./maze
Welcome to CS35 lab 05: The A-Maze-ing Race.
where is your maze file? test_data/cycle.map
Which search algorithm to use (BFS or DFS)? DFS
@@###
#@@@#
#.#@#
#..@@
####@

Invalid Inputs: Your maze program should gracefully handle the following cases of invalid input:

• The user provides a search type other than "BFS" or "DFS"
• The user provides an invalid maze file (to be handled by catching the exception from loadMap)

Memory Management

Your program should run without any memory errors. It's OK if your destructor(s) do not clean everything up, but you should at least make a reasonable attempt, and in any case, you should avoid dereferencing uninitialized memory.

For this part of your assignment, you will give written answers much in the same way as you did in Lab 03. Your submission must be in PDF format. To get you started with LaTeX, we've given you a WrittenLab.tex which contains the problems below. For further details about LaTeX, see the file LearningLaTeX.tex.

1. Prove each of the following claims by induction:
   • Claim 1: The sum of the first $n$ odd numbers is $n^2$; i.e. $$\sum_{k=1}^n (2k-1) = n^2\ .$$
   • Claim 2: $\sum_{k=1}^n k^2 = \frac{n(n+1)(2n+1)}{6}$.
   • Claim 3: $\sum_{k=1}^n \frac{1}{2^k} = 1-\frac{1}{2^n}$.
2. The function maxEven, given below in pseudocode, takes as input an array $A$ of $n$ integers and returns the largest even integer in the array. If no such integers appear in the array, it returns $-\infty$ (minus infinity). Using induction and loop invariants, prove that the maxEven function works correctly. (Hint: you should use the loop invariant "S(k): at the beginning of the loop iteration with $i == k$, max is equal to the largest even integer in the first $k$ elements of the array, or $-\infty$ if no such numbers exist.")

   function maxEven(A,n):
     max = -infinity
     for i = 0..n-1:
       if A[i] > max and A[i] is even then:
         max = A[i]
       end if
     end for
     return max
   end function

3. Dachshund Races. You are in charge of organizing a large dachshund race. There are 36 dachshunds, and you must determine the three fastest dachshunds by placing them into races. Unfortunately, your track only has space for six dachshunds at a time, and you have no timing equipment. You're able to race six dachshunds at a time, and have decided to run multiple races to determine the three fastest dachshunds. You can race each dachshund any number of times. However, you can only race six dachshunds at a time, and you cannot directly compare results from two different races (since you don't keep track of exact times).

   Give a method to determine the three fastest dachshunds. What is the minimum number of races you need to arrange?

For this and future labs, graders will assign minor penalties for poor commenting and coding style. Here are some style tips for this lab:

• You should pick meaningful variable names.

  // good
  int *array = new int[size];
  // bad
  int *a = new int[size];


• You should use correct and consistent indentation. Lines of code within a block should be indented two spaces further than lines surrounding them.*

    //good
    if(condition) {
      cout << "Test" << endl;
    }

    //bad
    if(condition) {
  cout << "Test" << endl;
       }


  *if your text editor's default indenting is four spaces instead of two, don't stress about it. Just be consistent when indenting.

• You should use a code block whenever possible, even if it's not necessary. This will help you avoid subtle/messy errors in the future.

  //good
  if(condition) {
    cout << "Something" << endl;
  }

  //legal but bad
  if(condition)
    cout << "Something" << endl;


• Do write comments at the top of each file, indicating your name and the purpose of the code file
• You don't have to write a comment for each line of code, but do write comments about meaningful chunks of code such as a loop, if/else statement, etc.
• Do write comments describing the purpose and signature of each function declaration. Use @param to describe an input parameter, @return to describe what gets returned, and @throws to describe exceptions that should be thrown. An example lies below:

  /**
   * Retrieves the first element of the list.
   * @return The element at index 0 of this list.
   * @throws runtime_error If the list is empty.
   */
  virtual T peekHead() = 0;



• We've given you STL implementations for each of the ADTs you've seen so far this semester. In particular, you didn't need to implement a Stack or Queue ADT. Give those implementations as an extra challenge. Do they perform better or worse than the STL implementations?
• Give some analysis which compares the performance of DFS and BFS over several graphs. Does one algorithm tend to find a path in fewer steps? Does one return a shorter path?
• In the Dachshund Race Problem, there were 25 dachshunds. Suppose you wanted to know the three fastest dachshunds out of a group of $n$ dachshunds? How many races would you need? Express your answer as a function of $n$ and do not use big-O notation.

These additional features are optional – we'll look at them, but they won't be for credit. Make sure you complete and push both parts of the main lab before starting any extra challenge, and note in your README file that you've done extra challenges so the graders know which version of your lab to grade. (There's a chance your added features will break our grading scripts; we'll grade the base version of your lab to ensure you don't get penalized in the off-chance your extra features break our grading scripts)

When you have completed your lab, answer a few short survey questions in the file README.md.

To summarize the requirements of this lab:

• You should have a working maze class.
• You should have a main function which provides a simple interface to solve maze problems.
• The input should be validated, and your code should contain no memory errors.
• You should have written answers to the analysis questions in a PDF document.

Once you are satisfied with your code, hand it in using git. Remember the add, commit, push development cycle. You can push as many times as you like, but only the most recent submission will be graded. You may want to run git status to confirm all modifications have been pushed.
